ZRJ3002-(n) ZORA CAT6A unshielded patch cord is suitable for structured cabling system. it can transmit digital, voice, data and video signals, and is suitable for all Ea-level channels and 6A-level applications.
1. Implementation standards: ISO/IEC11801, ANSI/TIA-568.2-D. 2. Plug technology: plug protection device design, perfect combination with crystal head and cable, elegant and durable. high-toughness long handle support at the tail, effectively relieves the suspension fatigue of the jumper during use and improves service life. high-temperature injection molding process, effectively improves transmission performance. 3. Conductor: multi-strand twisted copper soft conductor. 4. Cable structure: center cross skeleton line pair isolation technology, effectively reducing near-end crosstalk. 5. Crystal head: the front-end branch line part is shorter, reducing the length of the line pair twisting distance, ensuring the stability of the impedance of the two differential signals of the same line pair, and the three-pronged crystal head reed, reducing the contact resistance between the wire. 6. Support bandwidth: 500MHz. 7. A variety of colors are available, and the length can be customized according to the needs of the purchaser.
